DLD-M330C-640 HgCdTe cooled detector thermal Camera

Home / all / Thermal Camera&System / Online Thermal Camera /

DLD-M330C-640 HgCdTe cooled detector thermal Camera

DLD-M330C-640 HgCdTe cooled detector thermal Camera

DLD-M330C-640 HgCdTe cooled detector thermal Camera
DLD-M330C-640 HgCdTe cooled detector thermal CameraDLD-M330C-640 HgCdTe cooled detector thermal CameraDLD-M330C-640 HgCdTe cooled detector thermal CameraDLD-M330C-640 HgCdTe cooled detector thermal CameraDLD-M330C-640 HgCdTe cooled detector thermal Camera
CategoriesOnline Thermal Camera
BrandMSTAR Machine Vision System
Detector TypeHgCdTe cooled focal plane detector
Resolution640×512
Pixel Pitch15μm
Spectral Range3.7-4.8μm
NETD≤20mk
Frame rate50Hz
Focus15~330mm
Lens typeOptical continuous zoom lens
Download DOCpdf icon
Update TimeDecember 6,2022
Detail Information
320*256 / 640*512 CMT cooled FPA detector
- 640*512 HgCdTe cooled detector
- 50HZ Full real-time imaging, ultra long-distance observation
- 22x Optical continuous zoom, high sensitivity, clear image
- Preset position supported
- Quick Auto-focus

Item

DLD-M330-640

Detector

Detector type

HgCdTe cooled focal plane detector

Array  size

640×512

Pixel size

15μm

NETED

≤20mk

Frame rate

50Hz

Spectral range

3.7-4.8μm

lens

Focus

15~330mm

FOV

35.5°×28.73°~1.7°×1.3° ±5%

Lens type

Optical continuous zoom lens

Thermal operation

Preheating time

<8min25

Brightness/Gain

Auto/Manual

Polarity

Black/White-hot

Electrical zoom

2X

Calibration

Manual/auto

Image enhancement

Yes

Denoise

Yes

Power supply system

External power

DC 24V

Consumption

≤30W25

Environmental parameter

Working temperature

-40- +55

Storage temperature

-45- +65

Protection level

IP40

interface

Power supply interface

Yes

Analog video interface

PAL

Port

RS422

Distance

Detect the pedestrian

19800

Detect the vehicle

25300

Identify the pedestrian

6600

Identify the vehicle

12650
